Home /  News /  Company News

Great News! !World Industrial's Soft Bridge® Wins the "Golden Charge Award for Technological Innovation"

Post time: 2025.11.07 Source: Source:Shenzhen World Industrial Co.,Ltd Views: 19

On November 7, the "2025 Asia Charging Exhibition Appreciation Banquet and Golden Charge Awards Ceremony" was successfully held at the Pullman Shenzhen Hotel. Shenzhen World Industrial Co., Ltd.'s flagship product, the Soft Bridge®, was honored with the "Golden Charge Award for Technological Innovation" in recognition of its outstanding technological innovation.


The Soft Bridge® effectively minimizes its impact on circuit EMI by improving the diode's recovery characteristics, optimizing the softness factor (tb/ta) during the reverse recovery process, and optimizing the associated reverse recovery current change rate (diF/dt). This technological breakthrough brings four core values: enhancing overall system efficiency, reducing BOM costs, simplifying design complexity, and improving compatibility. Since its launch, the Soft Bridge® has been rapidly and widely adopted by the market, empowering upstream and downstream partners to jointly pioneer numerous groundbreaking fast-charging solutions.

The "Golden Charge Award" is dedicated to honoring every breakthrough and every dedication to craftsmanship in the charging sector. This award marks a new milestone for World Industrial. We will continue to uphold our spirit of innovation, deepen our expertise in power supply technology, and co-create a new future for fast charging with more superior products and solutions!
Prev: World Industrial Showcases EMC and Overvoltage Protection Innovations at EDTEST 2025 Summit Next: Journey into the Heart of Chip Tech: What an Amazing Trip!
