In the outdoor lighting sector, safety and stability are paramount! Shenzhen World Industrial Co., Ltd. (hereinafter referred to as "World Industrial") is proud to introduce the FS277ALED20P3C2 series, a dedicated Surge Protective Device (SPD) for outdoor LED lighting. Backed by patented invention technology and premium export-grade quality, this series delivers ultimate protection for our global customers!
I. Core Highlights
1. Patented Invention Technology for Precision Current Protection
Powered by World Industrial's exclusive patented invention, this SPD delivers industry-leading surge protection performance, serving as an "anti-lightning armor" for LED lighting systems.
Powered by World Industrial's exclusive patented invention, this SPD delivers industry-leading surge protection performance, serving as an "anti-lightning armor" for LED lighting systems.
2. 20kA Robust Energy Capacity for Instantaneous Surge Absorption
Featuring a standard discharge current of 10kA and a maximum discharge current of up to 20kA (8/20μs), combined with a 20kV open-circuit voltage tolerance, it effortlessly handles direct lightning-induced surges. With a line-to-line protective voltage of <1800V, it maintains exceptional stability even under severe impacts.
Featuring a standard discharge current of 10kA and a maximum discharge current of up to 20kA (8/20μs), combined with a 20kV open-circuit voltage tolerance, it effortlessly handles direct lightning-induced surges. With a line-to-line protective voltage of <1800V, it maintains exceptional stability even under severe impacts.
3. Wide Voltage Compatibility for Global Applications
Supporting nominal voltages of 90Vac-120Vac and 277Vac-347Vac, this device is fully compatible with single-phase power systems worldwide. From municipal engineering to international projects, it completely eliminates voltage adaptation challenges.
Supporting nominal voltages of 90Vac-120Vac and 277Vac-347Vac, this device is fully compatible with single-phase power systems worldwide. From municipal engineering to international projects, it completely eliminates voltage adaptation challenges.
4. Extreme Temperature Durability for Harsh Environments
Engineered to withstand extreme temperatures ranging from -50℃ to +125℃, and featuring an IP65 protection rating (excluding cable ends) alongside a UL-94V0/V1 flame-retardant housing, it ensures continuous and stable operation in freezing, scorching, and humid conditions, offering a significantly longer lifespan than comparable products.
Engineered to withstand extreme temperatures ranging from -50℃ to +125℃, and featuring an IP65 protection rating (excluding cable ends) alongside a UL-94V0/V1 flame-retardant housing, it ensures continuous and stable operation in freezing, scorching, and humid conditions, offering a significantly longer lifespan than comparable products.
5. Intelligent Monitoring with Clear Failure Alerts
The status indicator remains off during normal operation and stays steadily illuminated upon failure, allowing for rapid status assessment without professional tools. Supporting both single-wire and three-core cable connections, it offers flexible installation and zero-maintenance operation.
The status indicator remains off during normal operation and stays steadily illuminated upon failure, allowing for rapid status assessment without professional tools. Supporting both single-wire and three-core cable connections, it offers flexible installation and zero-maintenance operation.
6. Triple Certification Backing for Uncompromising Quality
Fully compliant with international standards including IEC61643-11, UL1449 4th Edition, and GB/T 18802.11, and certified under RoHS/REACH environmental directives, every aspect from raw materials to performance is rigorously controlled, providing a reliable endorsement for premium projects.
Fully compliant with international standards including IEC61643-11, UL1449 4th Edition, and GB/T 18802.11, and certified under RoHS/REACH environmental directives, every aspect from raw materials to performance is rigorously controlled, providing a reliable endorsement for premium projects.
II. Target Applications
Engineered with robust performance to withstand severe surge environments, ensuring LED lighting systems remain brilliantly illuminated even under extreme conditions!
